Mini Fermenter

Feature Description:

The mini fermenters are mainly used for home brewing or pilot system used for recipe researching in big breweries. These are well configured with brewhouse and other support unit that consists of the whole pilot brewing system.

Tanks can be jacketed and isolated, with cooling line preassembled, or to be single layer that can be kept in cold room etc

The material and production standard is the same as the bigger tanks used for micro or large breweries.

Capacity range: 50L 100L 200L 300L

Details:

● Domed top and cone bottom cone, cone angle: 60 degree

● With 25% head space for fermenation

● Wall thickness: 3mm

● Pressure: 2-3 bar / 15-30PSI

● Dimple plate cooling jacket, cylinder and bottom cooled, Polyurethane insulation

● With adjustable leg bolt or to be installed on trolley / frame

● Diaphragm pressure gauge with CIP arm

● Top: with CIP arm, breathe valve, optional dry hopping port, top manway

● Cylinder: Glycol inlet / oulet, PT100, sample valve, level tube (optional)

● Bottom: Racking arm (optional), bottom beer / yeast outlet

Optional:

● Racking arm

● Carbonation unit

● Frame with wheels for compact fermenter unit

● Chiller used for fermentation cooling
